OCPP Compliance Testing Tool
- 電気自動車充電器管理のプロトコル OCPP 1.6 準拠のテストツール
- 電気自動車の充電ステーションを管理するプロトコルである OCPP 1.6 (Open Charge Point Protocol) を実装したシステムが、OCPP仕様で定められているガイドラインに準拠しているかをセルフテストするためのツール。
SOAPとJSON に対応しており、セントラルシステムとチャージングステーションの両方のテストに使用できます。
OCPP Compliance Testing Toolは、以下の OCPP 1.6の機能をカバーしています。
・Core Profile
・Other OCPP functionalities :
- Reservation
- Local Authorization List
- Remote Trigger
- Smart Charging
- Authorization Cache
- Data Transfer
- Diagnostics
- Firmware Management
- Security
- メーカー
- Open Charge Alliance
https://www.openchargealliance.org/
取り扱い商品の一例
商品名 | 納品方法 | 納期 | 価格 | |
---|---|---|---|---|
OCPP Compliance Testing Tool - Individual | 電子デリバリー | お問い合わせください | お問い合わせください | |
OCPP Compliance Testing Tool - Institution | 電子デリバリー | お問い合わせください | お問い合わせください | |
OCPP Compliance Testing Tool - Adopter/Implementer | 電子デリバリー | お問い合わせください | お問い合わせください |
ご希望の商品にチェックを入れてボタンをクリックすることで、該当商品をお見積もりフォームへ追加できます。納品方法についてはこちらをご覧ください。
商品説明
【OCAについて】
Open Charge Alliance (OCA) は、
電気自動車(EV)に関するインフラを担う官民リーダーによるグローバルコンソーシアムです。
Open Charge Point Protocol (OCPP) や Open Smart Charging Protocol (OSCP)といった規格を通じて、
オープン標準を推進しています。
【ライセンスについて】
ライセンス価格はOCAのメンバーであるかどうかにより異なりますので、
お問い合わせの際にはエンドユーザー様が OCAメンバーであるかどうかをお知らせください。
また、ご所属が以下のいずれに当てはまるかにつきましても併せてお知らせください。
・Individual
・Institution
・Adopter/Implementer (※)
※規模につきましても、以下の選択肢よりお知らせください
< 1M | 1M < 10M | 10M < 50M | 50M+
ライセンス購入時には、以下のドキュメンテーションが付属します
- Test Case document with test cases describing each scenario separately
- For Charging Station 102 test cases
- For Charging Station Management System 70 test cases
- Installation manual
- User manual (Continuous Integration included
【OCPP Compliance Testing Tool のベネフィット】
・Can be used for conformance testing
・Can be used for test automation (Continuous Integration)
・Can be used for validation of OCPP 1.6 implementations
・Makes implementing OCPP 1.6 much easier
・Helps with integrating OCPP 1.6 implementations of different vendors
The tool will also be used in the future certification program.
You can use the tool to validate your implementation before you apply for OCPP 1.6 certification at a designated test lab.
【その他詳細】
Functionality based on :
- OCPP 1.6 Specification
- OCPP 1.6 Errata sheet
- OCPP 1.6 Security Whitepaper
Technical description :
- Runs on Java 1.8 (Java SDK required)
- Tested by OCA on Windows, Linux + Mac OS
- Tool runs locally on PC / laptop
- Internet connection needed for license activation
- Number of activations per license: 4
